Hot Rolled 316L Stainless STeel Plate 0.5 - 60.0mm SS Plate 1.4404 / AISI316L Stainless

Brand Name : TISCO BAOSTEEL

Model Number : 316L / 1.4404

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 4000-6000 USD/Ton

Payment Terms : T/T, Western Union

Supply Ability : 20Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : Stainless Steel Plate

Grade : 316L / 1.4404

Width : 1500mm 1219mm 1000mm

Surface : NO.1 2B

Brand : POSCO TISCO BAOSTEEL

Standard : ASTM A240/240M

Loading Port : Shanghai Port

Thickness : 0.6 - 30.0mm

Contact Now

Hot Rolled 316L Stainless STeel Plate 0.5 - 60.0mm SS Plate 1.4404 / AISI316L Stainless

Product name 316L Stainless steel plate
Standard GB,JIS,DIN,AISI,ASTM,AISI,ASME
Thickness 1.5mm-50mm
Width 1000,1219,1250,1500mm, or as your requirements
Length 2000,2438,2500,3000,6000mm, or as your requirements
MOQ 1MT
Surface No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film.
Packing standard export packing (inside:water proof paper,outside:steel covered with strips and pallets)
Cargo ready date within 25-35 days after confirming orders
Delivery Time About 5-7 days after receive the deposit.

ASTM A240 316/316l Stainless Steel Plate

In ASTM A240, type 316 and 316L is a chromium nickel austenitic steel, Element molybdenum addition can enhances corrosion resistance of stainless steel, which is the main factor that 316/316l is more corrosion resistant than 304/304l. When 316L steel of low carbon content is only a little higher than 316 steel on strength level. So sometimes grade 316l is almost the same as 316 grade. Another difference, 316l can be used for weld treatment as it contains lower carbon.

316/316L steel has outstanding corrosion resistant properties, whether it is atmospheric or oxidizing environment, even for marine atmosphere, it shows excellent corrosion resistance in welded state. Normally 316/316l steel shows no magnetic in annealed condition, cold drawn or cold rolling process may make it with little magnetic, and it can be fixed with further processing.

Applications of ASTM A240 316/316L

316/316L plate is used to manufacture products for applications that are exposed to salt water, acids such as sulfuric acid and chloride, petrochemicals and chemicals and high-heat such as engines and motors.Products include tanks, supports and frames, enclosures and housings, engine, motor and machinery components and parts.

Chemical Composition of 316/316L Steel Plate

Chemical Composition of 316/316L steel
Element 316 316L
Carbon 0.08 0.030 max
Chromium 16.0-18.0 16.0-18.0
Nickel 10.0-14.0 10.0-14.0
Molybdenum 2.00-3.00 2.00-3.00
Manganese 2.00 2.00
Silicon 0.75 0.75
Nitrogen 0.10 0.10
Phosphorus 0.045 0.045
Sulfur 0.030 0.030

Mechanical Properties of 316/316L Steel Plate

Mechanical Property of 316/316l 316 316L
Yield Strength, min. (ksi) 30 25
Tensile Strength, min. (ksi) 75 70
Elongation, min. (%) 40 40
Hardness, max. (Rb) 95 95

Stainless Steel Standards of 316/316L steel

Steel Standards of 316/316L
316 316L
ASTM A240 ASTM A240
ASTM A666 ASTM A666
ASME SA240 ASME SA240
AMS 5524 AMS 5507

Hot Rolled 316L Stainless STeel Plate 0.5 - 60.0mm SS Plate 1.4404 / AISI316L StainlessHot Rolled 316L Stainless STeel Plate 0.5 - 60.0mm SS Plate 1.4404 / AISI316L StainlessHot Rolled 316L Stainless STeel Plate 0.5 - 60.0mm SS Plate 1.4404 / AISI316L StainlessHot Rolled 316L Stainless STeel Plate 0.5 - 60.0mm SS Plate 1.4404 / AISI316L Stainless
