Hot Rolled 317L 3.0 - 12.0mm 317L Alloy Stainless Steel in Coils

Name: Hot Rolled 317L 30 120mm 317L Alloy Stainless Steel in Coils
Brand: TISCO BAOSTEEL
Price: 4000 USD

China Hot Rolled 317L 3.0 - 12.0mm 317L Alloy Stainless Steel in Coils factory

Brand Name : TISCO BAOSTEEL

Model Number : UNS S31703 / 317L

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 4000-6000 USD/Ton

Payment Terms : T/T, Western Union

Supply Ability : 20Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Products : Stainless Steel Plate

Grade : UNS S31703 / 317L

Width : 1500mm 1219mm 1000mm

Surface : NO.1 2B

Brand : POSCO TISCO BAOSTEEL

Standard : ASTM A240/240M

Loading Port : Shanghai Port

Thickness : 0.6 - 30.0mm

Contact Now

Hot Rolled 317L Stainless Steel Plate 3.0 - 12.0mm SS Plate TISCO BAOSTEEL 317L Alloy Stainless Steel in Coils

Specification of SS 317L plate

specifications	ASTM A240 / ASME SA240, EN 10088-2
Standard	ASME, ASTM, DIN, BS, EN
Thickness	1 to 200mm
Length	2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface	2B, etching, BA,, NO.4, NO.8, Brush, NO.1, mirror, 8K, hair line, embossed, 2D, checkered, sand blast, etc
Origin	China
Technique	Cold Rolled and Hot Rolled
Width	1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm etc
Stainless Steel Sheet Finish	Cold rolled sheet (CR), SATIN (Met with Plastic Coated), BA NO(8), Hot rolled plate (HR), 2B, 2D
MTC	Available as per EN 10204 3.1, Mill Test Certificate
Brand Name	TISCO BAOSTEEL POSCO JISCO LISCO
Container	40ft HC: 12032m
Form	Coils, Foils, Shim Sheets, Rolls, Plain Sheets, Ring (Flange), Strip, Perforated Sheets, Blank (Circle), Chequered Plate, Flats, etc.
Price term	CFR, Ex-Work, FOB, CNF, CIF
Size	40ft GP: 12032mm x 2352mm x 2393mm
Size	20ft GP: 5898mm x 2352mm x 2393mm

Detail Size of 317L Stainless Steel Plate We have

Grade

304L / S30403

Thickness

Cold rolled: 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm

Hot Rolled : 4.0mm 5.0mm 6.0mm 8.0mm 10.0mm 12.0mm 14.0mm 16.0mm 20.0mm 25mm 30mm 35mm 40mm 45mm 50mm 55mm 60mm

Standard Size

1000*2000mm 1219*2438mm 1500*6000mm

About 317L Stainless Steel

Alloy 317L is a molybdenum containing, low carbon austenitic stainless steel with increased additions of chromium, nickel, and molybdenum for better corrosion resistance and increased resistance to chemical attack for sulfurous, acetic, formic, citric, and tartaric acids. Due to its low carbon content, 317L also provides resistance to sensitization when welded and higher creep, stress to rupture, and tensile strength at elevated temperatures. It is non-magnetic in the annealed condition but may become slightly magnetic after welding.

Chemical Properties:

%	Cr	Ni	C	Si	Mn	P	S	Mo	Fe
317L	min: 18.0 max:20.0	min: 11.0 max: 15.0	0.035 max	0.75 max	2.0 max	0.04 max	0.03 max	min: 3 max: 4	balance

Mechanical Properties:

Grade	Tensile Strength ksi (min.)	Yield Strength 0.2% Offset ksi (min.)	Elongation - % in 50 mm (min.)	Hardness (Brinell) MAX	Hardness (Rockwell B) MAX
317L	75	30	40	217	95

Application of 317L Stainless Steel

Alloy 317L is commonly used to handle sulfur, pulp liquor, acid dyestuffs, acetylating and nitrating mixtures, bleaching solutions, severe coal and oil, and many chemical compounds. Some other applications that use alloy 317L include:

Paper and pulp handling equipment
Chemical and petrochemical processing equipment
Condensers in fossil and nuclear fueled power generation stations
Food processing equipment
Textile equipment

Hot Rolled 317L 3.0 - 12.0mm 317L Alloy Stainless Steel in Coils
