ASTM A276 304 316L Stainless Steel Angle Bar Equal Angle / Stainless Steel U Channel Bars

Brand Name : DELTA

Model Number : 201 304 316L 321 309S 310S 2205 17-4PH 2507

Certification : ISO

Place of Origin : China

MOQ : 500 kgs

Price : 2400 - 3500 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 20Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : standard packing for export

Shape : Angle Bar / channel bar

Standard : ASTM EN GB JIS

Grade : 201 304 316L 309S 310S 321 2205 2507.etc

Application : Construction,Industry,surgical tools,seawater equipment.,kitchenware

Length : Customers' Requirements,5.8m,6m,2m-6m,or as required

Size : custom as request

Packing : Standard Seaworthy Package,In wooden cases(for FCL/ LCL shipment)

Service : Cutting, surface finishing

Contact Now

ASTM A276 304 316L Stainless Steel Angle Bar Equal Angle / Stainless Steel U Channel Bars

Products Stainless Steel Angle Bar / Stainless Steel Channel Bar
Grade 201 304 304L 310S 316L 2205.etc
Finishing Hot rolled
Diameter 30*30*3- 120*120*12
Length 6m or custom cutting as request
Service Cutting
MOQ 500 Kgs
Deliver time 10 - 15 Days based on the quantity
Packing wooden box, or packing as request
Loading Port Shanghai Port. Ningbo Port
Other Shape Round, Square, Flatness, Hexagonal , Angle, Channel
Company Type Factory

Stainless Steeel Equal Leg Angle, Suppliers of ASTM A484 Stainless Steel 304L U Channel, 304L SS Anchor Chain Exporter, Stainless Steel 304 Angle Price, Stainless Steel 304L H Beam, SS WERKSTOFF NR. 1.4306 I Beam Manufacturer, SS 304L Channel Bar

Stainless Steel Angles are manufactured using high-grade steel, which contains chromium, nickel, and additional molybdenum, niobium, titanium, and nitrogen. These additional elements offer excellent tensile strength, high surface finish, outstanding corrosion & oxidation resistance, and good mechanical properties. We offered these SS Angles in various types like Stainless Steel Unequal Angles, Stainless Steel Equal Angles, etc.

imilarly, we have a large stock of 304 Stainless Steel Channels in different types such as Stainless Steel C Channels, 304L Stainless Steel U Channels and more. Also, we are a specialist in manufacturing 304L Stainless Steel Flats in types like Stainless Steel 304L Brush Polished Flat, etc. All these Stainless Steel products are available in various material grades including 304, 304L, 310, 310S, 321, 321H, 347, 347H, and 904L.

304 Stainless Steel Angles, Channels and Flats are widely used in paper & pulp, construction, piping, water treatment applications, raceways, braces and frames for machinery and housing in corrosive environments, etc. If you want to buy these Stainless Steel Products at most affordable prices

304 Stainless Steel Angle, SS 304 Channel & Flat Bar Specification :

Specifications ASTM A 276/A 276M,A 484/A 484M,A 564/A 564M,A 582/A582M,A 638 /A 638M,A705/A705M
Dimensions EN, DIN, JIS, ASTM, BS, ASME, AISI
SS 304L Channel 40mm*20mm~300mm*300mm
SS 304L Angle 5mm to 9mm
SS 304L Beam 3″ thru 12.31″
SS 304L Chain 1/8 inch – 1/2 inch Diameter
Thickness 3.0mm – 120mm
Length 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
Type Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain

SS 304 Angle, Channel Bar, Steel 304 Flat Bar Chemical Composition

Grade C Mn Si P S Cr Mo Ni N
SS 304/304L 0.035 max 2 max 1.0 max 0.045 max 0.030 max 18 – 20 – 8 – 13 –

Mechanical Properties of SS 304 Channel Bar, 304 Angle, SS 304 Flat Bar

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1400 °C (2550 °F) Psi – 75000, MPa – 515 Psi – 30000, MPa – 205 35 %

Equivalent Grades of Stainless Steel 304 Flat Bar, 304 Angle & SS 304 Channel Bar

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS304/304L 1.4306/1.4307 S30403 SUS 304L 3304S11 03Х18Н11 Z3CN18‐10 X2CrNi18-9 / X2CrNi19-11

ASTM A276 304 316L Stainless Steel Angle Bar Equal Angle / Stainless Steel U Channel BarsASTM A276 304 316L Stainless Steel Angle Bar Equal Angle / Stainless Steel U Channel BarsASTM A276 304 316L Stainless Steel Angle Bar Equal Angle / Stainless Steel U Channel Bars

ASTM A276 304 316L Stainless Steel Angle Bar Equal Angle / Stainless Steel U Channel Bars
