Heat Resistant 310H Stainless Steel Plate AISI310H 3.0 - 40.0mm in 1500mm Width from TISCO

Product Categories
JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Heat Resistant 310H Stainless Steel Plate AISI310H 3.0 - 40.0mm in 1500mm Width from TISCO

Brand Name : DELTA

Model Number : 310H

Certification : ISO

Place of Origin : China

MOQ : 400 kgs

Price : 3200 -5220 USD/Ton

Payment Terms : L/C, T/T, Western Union

Supply Ability : 10 Ton per week

Delivery Time : 5 - 12 days based on the quantity

Packaging Details : wooden pallets + waterproof paper

Products : stainless steel plates

Grade : 310H

Standard size : 1000*2000mm 1219*2438mm 1500*6000mm

Thickness : 0.6- 40.0mm

Brand : TISCO BAOSTEEL POSCO LISCO

Loading Port : Shanghai Port

MOQ : 200 kgs

Packing : wooden pallets + waterproof paper

Contact Now

Heat Resistant 310H Stainless Steel Plate AISI310H 3.0 - 40.0mm in 1500mm Width from TISCO

More Informations of our Products

Product
Stainless Steel Sheet/Plate
Standard
ASTM A240,GB/T3280-2007,JIS4304-2005,ASTM A167,EN10088-2-2005,etc
Material
310S,310,310H,309,309S,316,316L,316Ti,317,317L,321,321H,347,347H,304,304L,302,301,
201,202,403,405,409,409L,410,410S,420,430,631,904L,Duplex,etc
Surface
2B,2D,BA,NO.1,NO.4,NO.8,8K,mirror,checkered,embossed,hair line,sand blast,Brush
Thickness
Cold Rolled:0.3-6mm
Hot Rolled: 3-20mm
Width
1000mm,1219mm,1500mm,1800mm,2000mm,2500mm,,etc
Length
2000mm,2440mm,3000mm,5800mm,6000mm,etc
Package
Covered with a layer of plastic film and cardboard,packed on the wooden pallets/ iron packing,bound with iron belt,loaded in the containers.
Price Terms
Ex-Work,FOB,CFR,CIF,FCA,etc
Payment Terms
TT,L/C at sight ,western Union,etc.

Stainless steel grade 310H has carbon content and is a preferred choice for high temperature applications. This steel has good resistance to oxidation at temperatures of up to 1040°C (1904°F) in intermittent service and 1150°C (2102°F) in continuous service. It is widely used in environments where sulfur dioxide gas is present at high temperatures; however it is recommended that this steel should not be continuously used at 425-860°C (797-1580°F) range due to carbide precipitation.

The following datasheet provides an overview of stainless steel grade 310H.

310H Stainless Steel Plate We Have Stock

3.0*1500*6000mm 4.0*1500*6000mm 5.0*1500*6000mm 6.0*1500*6000mm
8.0*1500*6000mm 10.0*1500*6000mm 12.0*1500*6000mm 14.0*1500*6000mm
15.0*1500*6000mm 16.0*1500*6000mm 18.0*1500*6000mm 20.0*1500*6000mm
22.0*1500*6000mm 25.0*1500*6000mm 30.0*1500*6000mm 32.0*1500*6000mm
35.0*1500*6000mm 38.0*1500*6000mm 40.0*1500*6000mm

Chemical Composition OF 310H Stainless Steel Plate

The chemical composition of grade 310H stainless steel is outlined in the following table.

Element Content (%)
Iron, Fe 49.075-45.865
Chromium, Cr 24-26
Nickel, Ni 19-22
Manganese, Mn 2
Silicon, Si 0.75
Phosphorous, P 0.045
Carbon, C 0.040-0.10
Sulfur, S 0.03

Mechanical Properties of 310H Stainless Steel Plate

The mechanical properties of annealed grade 310H stainless steel are displayed in the following table.

Properties Metric Imperial
Tensile strength 515 MPa 74694 psi
Yield strength 205 MPa 29732 psi
Modulus of elasticity 200 GPa 29000 ksi
Shear modulus 77.0 GPa 11200 ksi
Poissons ratio 0.3 0.3
Elongation at break (in 50 mm) 40% 40%
Hardness, Rockwell B 95 95
Hardness, Brinell 217 217

Applications of 310H Stainless Steel Plate

Grade 310H stainless steel is chiefly used in the heat treatment industry, and the chemical process industry.

The following are the specific areas of applications:

  • Fans
  • Trays
  • Baskets
  • Rollers
  • Burner parts
  • Oven linings
  • Tube hangers
  • Retorts linings
  • Conveyor belts
  • Refractory supports
  • Containers for hot concentrated acids, ammonia, and sulfur dioxide
  • Used along with hot acetic and citric acid in the food processing industry.

Heat Resistant 310H Stainless Steel Plate AISI310H 3.0 - 40.0mm in 1500mm Width from TISCOHeat Resistant 310H Stainless Steel Plate AISI310H 3.0 - 40.0mm in 1500mm Width from TISCOHeat Resistant 310H Stainless Steel Plate AISI310H 3.0 - 40.0mm in 1500mm Width from TISCOHeat Resistant 310H Stainless Steel Plate AISI310H 3.0 - 40.0mm in 1500mm Width from TISCO
